*쿼드(Quad) 모델(Model) S-1 북쉘프 스피커*

*Specifications*

General Description
2Way Standmount / Bookshelf Speaker

Bass / Midrange Driver
1 x 100mm (4”) Woven Kevlar Cone

Treble Driver
1 x 12 x 45 mm True Ribbon

Sensitivity
(2.83V @ 1m): 84dB

Recommended Amplifier Power
25-150 Watts

Peak SPL
96dB

Nominal Impedance
8Ω Compatible

Minimum Impedance
4.2Ω

Frequency Response
58Hz ~ 20kHz (+/-3dB)

Bass Extension (-6dB)
55Hz

Crossover Frequency
3.2kHz

Enclosure Type
Vented Box Loudspeaker

Transducer Complement
2-Way

Dimensions (H x W x D)
285 x 156 x 270mm

Weight : 5.2kg
